Weight
kg 4500
Dimensions closed machine with lifted column:
Length 2.100 mm Width 2350 mm Height 2670 mm (without pole slide)
Movements hydraulic
1. Hammer starter stroke
2. Up/down movement of the hammer trolley 3. In/out movement of the slide stroke 600 mm
4. Stroke translator 130+130 mm
5. Column inclination from +10° to -51°
6. Slide inclination (training) from + 9,5° to -9,5°
7. Down/up movement of the column stroke 500 mm 8. Left track control
9. Right track control
Power Oil sets on the machine
180 BAR
Hydraulic system
to open cicuit
Hydraulic pump
at gear
Capacity oil tank
140 LT
Translation’s speed of machine
1,92 3,33 KM/H
Engagement in HP
47,3
Maximum highest post
4.400 mm/ 5200 mm/ 6000 mm
